I have seen a lot of confusion about how types work in Godot Engine. Specifically, the difference between RefCounted, Object and built-in types like String or Color. At the end of this post, you will understand the exact differences between them.

The Good: RefCounted and Built-in Types

Many types in Godot such as AStar3D are of type RefCounted. Godot will keep track of how many references you have for a given instance. If the reference count becomes 0, the instance will be freed:

extends Node

func fun_with_refs() -> void:
   var my_ref = AStar3D.new() # AStar3D is of type RefCounted

func _ready() -> void:
   fun_with_refs()
   # the AStar3D instance will be gone! Nothing is referencing it!

This can be extremely handy: you don't actually have to worry about freeing objects or any sort of memory management. Godot will take care of it automatically. Prefer RefCounted if you don't want to worry about freeing instances and you have mostly short-lived objects anyways.

For in-built types like Color or String, Godot utilizes value semantics, this means that when you assign a color or string, it will create always an independent copy.

var a = Vector2(5, 10) # Vector2 is an inbuilt-type
var b = a
b.x = 99

print(a) # (5, 10)
print(b) # (99, 10)

The Bad: Object

Well... not really bad. Just bad for beginners. Object type can bite you if you don't actually understand how it works! Godot will not free objects for you. When you are not careful, it can lead to a memory leak:

extends Node

func memory_leak() -> void:
   var node = Node.new() # Node is of type Object

func _ready() -> void:
   memory_leak()
   # oops, memory for the node instance is still reserved!

In order to free Object you have to call .free() on it. You are in luck, though: most Object instances that Godot creates (like nodes) it will free for you! So while technically, Object requires manual memory management, Godot will do a lot for you. However, when rolling your own Object types you need to be careful!

The Ugly: Invisible Side-Effects

I have been recently contributing again to the FMOD GDExtension by utopia-rise because I was trying to investigate an issue in my game where no sound was playing. I won't go into too much technical detail here, but FMOD basically is an audo engine that I am using for my game. FMOD has the concept of "audio banks" that you gotta load at runtime, and those banks contain the audio to play. The code usually looks like this:

# init.gd autoload script
extends Node

func _init() -> void:
    FmodServer.load_bank("res://fmod/main.bank", FmodServer.FMOD_STUDIO_LOAD_BANK_NORMAL)

This used to work fine but at some point, it stopped working. After a long time of debugging, it turned out that the signature of load_bank had been changed. FmodBank no longer was of type Object but of type RefCounted!

If you have paid attention before, you should already know what the problem is: the GDExtension correctly loads the main.bank file into memory but we are actually not referencing it! Godot will then go ahead and free the instance again (because it is a RefCounted and its reference count reaches 0). So the correct fix is this:

# init.gd autoload script
extends Node

var banks = []

func _init() -> void:
    banks.append(FmodServer.load_bank("res://fmod/main.bank", FmodServer.FMOD_STUDIO_LOAD_BANK_NORMAL))

since banks itself is a reference that will stay around as long the init.gd autoload is around (for the entire duration of the game's runtime). We are saved!

Confusion about valid instances

Before we finish, I wanted to say a few more words about is_instance_valid. Code like this may seem confusing at first:

var my_color = Color(255, 255, 255)
print(is_instance_valid(my_color)) # returns false

but this is intended behaviour: Color is an in-built type and won't have an instance id. is_instance_valid only operates on instance ids so Godot cannot know if it is valid or not -> it will always be false.

I hope this was somewhat useful. If you have follow up questions, you can always reach me on 🐘Mastodon or over at ⛅BlueSky.
